TG20KW-2
ENGELEC
Micro Hydro Turbine is a small-scale generator for domestic use. It’s referred to as a “micro turbine.”
Micro generators are small in dimension and produce comparatively small force, suitable for small-scale energy production. Micro generators are relatively a new discovering in the field of power generation.
Recent expertise and research has now made the invention of such a compact generator possible. Micro hydro mills are indeed successors of turbochargers used in trucks, and APU’s utilized in airplanes. What is absolutely a necessary characteristic of those turbines is that these can be utilized to generate electricity as well as to offer heating at the similar time.
Micro turbines come in several sizes that correspond to their output electrical power. There are “industrial micro generators”, “mini micro turbines” and “micro generators”. An industrial micro turbine is capable of producing more than 1000 KW of electricity.
Such a powerful generator can power a complete town. Mini micro turbines are limited to an output energy range of 500 KW to 1000 KW. These are economical versions and are suitable for small areas consisting of some houses. Then there are micro turbines which can be designed to meet the needs of a single home only. These are able to produce power ranging from 20 KW to 500 KW.
Though it may look the weakest among the three, it has its advantages. It is compact in measurement and is de facto cheap.
Micro hydro generator is an ideal solution for those who want ample electrical energy to light up their houses.
| Main Parameters of 30kw Hydro Turbine | ||||
| No. | Items | Parameters | Remarks | |
| 1 | Model | TG30KW-2 | Dual Nozzle Turgo Turbine | |
| 2 | Rated Head | 38–45 | (meters) | |
| 3 | Rated Flow | 90–120 | (l/s) | |
| 4 | Output | 30000 | (W) | |
| 5 | Efficiency | 70 | (%) | |
| 6 | Pipe Diameter | 250-300 | (mm) | |
| Generator | ||||
| No. | Items | Parameters | Remarks | |
| 1 | Model | SF-30-4/430 | Permanent Magnet Generator | |
| 2 | Style | PMG | ||
| 3 | Output | 30000 | (W) | |
| 4 | Voltage | 230 or 110 | (V) | |
| 5 | Current | 50 | (A) | |
| 6 | Frequency | 50 or 60 | (HZ) | |
| 7 | Rotary Speed | 1500 | (RPM) | |
| 8 | Phase | Three | (Phase) | |
| 9 | Power Factor | 1.0 | ||
| 10 | Altitude | ≤3000 | (meters) | |
| 11 | Insulation Grade | B / B | ||
| 12 | Protection Grade | IP44 | ||
| 13 | Temperature | －25～＋50 | ℃ | |
| 14 | Relative Humidity | ≤90 | % | |
| Control Box / Control Panel | ||||
| No. | Items | Parameters | Remarks | |
| 1 | Model | WY30-1 | ||
| 2 | Safety Protection | Short circuit Protection | ||
| 3 | Insulation Protection | |||
| 4 | Over Load Protection | |||
| 5 | Grounding Fault Protection | |||
| Packing | ||||
| No. | Items | Parameters | Remarks | |
| 1 | Packing Material | Fiberboard | ||
| 2 | Packing Size | 120×90×115 | (CM) | |
| 4 | Gross Weight | 615 | (KGS) | |
