TG20KW-2
ENGELEC
China manufacturer of 20kw micro hydro power generation, small hydro power plant, mini hydro power systems and pico hydro power generators.
cmakes use of water to generate electricity. Isn’t it surprising?
Now, this electricity just isn’t in watts but in tons of watts. Which means that you need to use this state-of-the-artwork generator to energy your total house. With this technology in hand, you don’t must pay enormous sums of cash on your fuel-stuffing turbines nor you must worry about paying electric bills. You just must feed the generator with some water and it starts working.
Micro Hydro Turbine is actually a hydro energy generator; a machine which generates electricity by utilizing water.
You’ll discover different types of hydro power generators, starting from huge generators for industrial makes use of as well as small, compact options for homes.
The sizes of those turbines rely on their use and requirement of electrical energy. Large hydro energy generators are highly effective sufficient to carry the electrical requirements of a complete town on its shoulders.
This is accompanied by its disadvantage that it occupies too much space and requires a dedicated land for its installation. Small generators, on the contrary, are in a position to slot in wherever in the neighborhood of a home, however can solely energy a single house.
| Main Parameters of 20kw Hydro Turbine/ 20kw hydro generator | ||||
| No. | Items | Parameters | Remarks | |
| 1 | Model | TG20KW-2 | Dual Nozzle Turgo Turbine | |
| 2 | Rated Head | 30–45 | (meters) | |
| 3 | Rated Flow | 60–100 | (l/s) | |
| 4 | Output | 20000 | (W) | |
| 5 | Efficiency | 70 | (%) | |
| 6 | Pipe Diameter | 250-300 | (mm) | |
| Generator | ||||
| No. | Items | Parameters | Remarks | |
| 1 | Model | SF10-4 | Permanent Magnet Generator | |
| 2 | Style | PMG | ||
| 3 | Output | 20000 | (W) | |
| 4 | Voltage | 230 or 110 | (V) | |
| 5 | Current | 50 | (A) | |
| 6 | Frequency | 50 or 60 | (HZ) | |
| 7 | Rotary Speed | 1500 | (RPM) | |
| 8 | Phase | Three | (Phase) | |
| 9 | Power Factor | 1.0 | ||
| 10 | Altitude | ≤3000 | (meters) | |
| 11 | Insulation Grade | B / B | ||
| 12 | Protection Grade | IP44 | ||
| 13 | Temperature | －25～＋50 | ℃ | |
| 14 | Relative Humidity | ≤90 | % | |
| Control Box / Control Panel | ||||
| No. | Items | Parameters | Remarks | |
| 1 | Model | WY20-1 | ||
| 2 | Safety Protection | Short circuit Protection | ||
| 3 | Insulation Protection | |||
| 4 | Over Load Protection | |||
| 5 | Grounding Fault Protection | |||
| Packing | ||||
| No. | Items | Parameters | Remarks | |
| 1 | Packing Material | Fiberboard | ||
| 2 | Packing Size | 120×90×115 | (CM) | |
| 4 | Gross Weight | 380 | (KGS) | |
Contact ENGELEC Hydro for a Quick Quote on 20kw hydro generator.
