EESWS 400W
ENGELEC
Availability: | |
---|---|
EESWS Series 400W Wind/solar Hybrid Controller
Applications
Ø Power supply for those unmanned regions like mobile communication station, high way, the coastal islands, remote mountainous regions and border posts.
Ø Regional research projects, government demonstration projects, landscape lighting projects for those places with insufficient power or power shortages.
Features
Ø Wind&Solar complementary controller in high quality.
Ø LCD Display. Easy setup.
Ø RS232/RS485/RJ45/GPRS /Bluetooth Optional (For those with GPRS/Bluetooth/RJ45 can also be monitored through App.)
Technical Parameters
Model | EESWS04-12 |
Wind Turbine Input | |
Rated input power | 400W |
Rated input voltage | 14Vdc |
Input voltage range | 0~16Vdc |
Rated input current | 34Adc |
Brake by hand | Press button “Enter” “Esc” at the same time to unload completely. Then recover by hand. |
Brake by over current | 34A(factory default,0~34A settable)Unload completely when reached the set current, and recover automatically after working 10mins. |
Brake by overvoltage | Refer to “output overvoltage” control |
Brake by over wind speed(optional) | 14m/s(0-30m/s settable),Unload completely when reached the set wind speed, and recover automatically after working 10mins. |
Brake by over rotational Speed(optional) | 500r/min(factory default,0~1000r/min settable)Unload completely when reached the set rotational speed, and recover automatically after working 10mins. |
PV Input Parameters | |
Rated input power | 150W |
Max. open circuit voltage | 24V |
Rated input current | 13A |
Reversed connection protection | YES |
Charge Parameters | |
Rated battery voltage | 12V |
Temperature compensation function(optional) | -3mV/℃/2V |
Output Parameters | |
Rated output voltage | 12V |
Start unload voltage | 13.5V(factory default,11Vdc~16Vdc settable) |
Complete unload voltage | 14.5V(factory default, add 1V to the start unload voltage) |
Max. Output current | 34A |
DC load output | |
Output loops | 2 loops |
Output control mode | Both 2 loops could be set in 7 modes, such as light control on&off, light control on and time control off. |
Output voltage range | 10.8V~16V |
Undervoltage recovery point | Refer to "rated battery voltage" |
Rated output current | 10A/each loop |
Overload protection | 120% rated DC output -1min,150% rated DC output -10s |
Short circuit protection | 200% rated DC output, instant protection |
General Parameters | |
Rectifier mode | Uncontrolled rectifier |
Display mode | LCD |
Display information | Battery voltage, wind turbine voltage/current/ power, PV power/voltage/current, light control-on voltage, light control-off voltage, time control duration, load current and so on. |
Monitoring mode(optional) | RS232/RS485/RJ45/GPRS/Bluetooth/Zigbee |
Monitoring Contents | Real-time display: Battery voltage, wind turbine voltage/current/ power, PV power/voltage/current, wind power generation capacity, solar power generation capacity, Battery status, wind turbine status, day and night, DC overload, DC load short circuit, and so on. |
Parameter setting: Output overvoltage point, wind turbine over current point, wind turbine start voltage, DC load overvoltage/undervoltage recovery point, output mode choice for two loops, light control on voltage, light control off voltage, and wind turbine brake settings. | |
Lightning protection | YES |
Conversion efficiency | ≥95% |
Static loss | <0.5W |
Environment temperature | -20℃~+40℃ |
Humidity | 5%~95%,No condensing |
Noise | ≤65dB |
Cooling mode | Natural cooling |
Installation mode | Wall-mounted |
Cover protection class | IP52 |
Product dimension(W*H*D) | 150×143×83mm |
Product net weight | 1.8kg |
Note: the listed specs are just for your reference |
